PVC/Veneer banding furniture edge bander NE500

PVC/Veneer banding furniture edge bander NE500

Brand Name
Gewinn
Price Terms
EXW,FOB,CIF,CFR
Place of Origin
Guangdong China(Mainland)
Minimum order
1 set
Packaging Details
Standard exporting package
After-sales Service Provided
Engineers available to service machinery overseas
Delivery Detail
30 days after order confirmed
Quick Details
  • Condition:New

  • Place of Origin:Guangdong, China (Mainland)

  • Model Number:NE500

  • After-sales Service Provided:Engineers available to service machinery overseas

  • Touching control screen:Delta

  • PLC&Fenquency:Delta

  • pneumatic component:Korean imported pneumatc device

  • End-trimming:American "Parker"

  • trimming motor:High speed motor with 2 years warranty

  • low voltage apparatus:Schneider

  • tracking wire:Germany wire

  • pathway:extra heavy

  • working voltage:380V/50HZ/3 phase

  • heat-up time:20 minutes

Packaing & Delivery
Packaging Details:standard export packing/as you require
Delivery Detail:20-30 days

Automatic edge banding machine



This Automatic edge banding machine is can band PVC, Veneer tape.Suitable for home use cabinet, closet, drawer and office furniture manufacturing. Precise trimming unit is helpful to make smooth product.

Operation



undefined                               Heating                                       Feeding                                  End trimming

     Rough&Fine trimming                                  Scrape                                      Buffing

Machine companent



undefined

           Korean pneumatic unit             Schneider low-voltage protecting      Durable Germany wire

undefined

       Quality high speed motor                    Germany “SIKO”              “DELTA” PLC

Machine Parameter

SpecificationNE550RNE500RNE400RNE550NE450NE500NE400NE300NE200
Min. Effectiven Workpiece Width60mm
Min. Workpiece Length150mm
100mm
Min. Workpiece Size (All Size)100×150mm100×100mm
Workpiece Thickness10-60mm
Edge Height15-65mm
Edge Thickness0.4~3mm
Conveyor Speed12~16~20 m/Min
Total Power17KW11.5KW10KW14.7KW12.5KW10.5KW8KW8KW7.3KW
Compressed Air Pressure6.5kg/cm³
Voltage380V/50Hz/3phase
Total Weight2450KG2150KG1900KG1950KG1800KG1650KG1500KG1350KG1150KG
Overall SizeL
6610mm5660mm5210mm5400mm5000mm4500mm4000mm3550mm2910mm
W X H1000×1600mm1000×1420mm
