Gewinn

Company Advantages
1. All designs of come from professional designers. Gewinn high frequency wooden frame jointing machine is available with us in different varieties which fulfil the multiple requirements of our clients for maximum efficiency and optimum performance
2. This product can ensure high and large production rate. Manufacturers or producers can use this product to produce goods with larger quantity and better quality. The entire range is developed under the guidance of expert professionals, which holds extensive knowledge of this domain
3. The product poses no risk of electric shock. Having passed a dielectric voltage-withstand test, it is guaranteed that it can withstand high voltage. We ensure that the price of this woodwork machine is less and well within the affordability of our clients
4. The product features good water purification. The built-in filter cotton, which has excellent absorption, can effectively remove the rust, areia, or other impurities. These wood sanding machines are provided in different specifications to suit the demands of customers

Quick Details

• Condition:New

• Spindle Speed:6750r.p.m

• Air Pressure:6-8 bar

• Max. Working Width:150mm

• Max Working Height:150mm

• Model Number:FJL 150-8A

• Voltage:380V

• Power(W):58.75kw

• Dimension(L*W*H):18000x6000mm

• Weight:9T

• Certification:CE , IQNet

• Warranty:one year

• After-sales Service Provided:Engineers available to service machinery overseas

---

Packaging & Delivery

---

Expert in Finger Jointing Line for 27 years

                                                           ---The leading Finger Jointing Technology in China

Our finger jointing line, offers a particularly workable solution for length joints

processing for both vertical and horizontal finger joints ,with belt conveyor, finger

joint shaper (with glue), roller conveyor, chain conveyor, using extremely user-friendly , easy-operated, noise-free system to achieve high precision effect



Model NO.: FJL 150-8A



This finger jointing line  is recognized as the most stable method of creating

 length joints between two solid wood or wooden composite components. It is used in

 order to produce very long wood components or to separate out knots and cracks which

 lower the strength. Using finger joints it is possible to joint short pieces of wood

 into one, in principle, infinitely long strand of wood.











A- Belt Conveyor

 B- Automatic finger joint shaper - MXB3515B-A

 C- Belt Conveyor

 D- Automatic finger joint shaper (with glue) - MXB3515B-B

 E- Roller conveyor

 F- Chain conveyor

 G- Automatic finger joint press – MHB1560B-C







1. Full automatic finger jointing line, to complete the process of wood finger shaping, gluing,

 conveying, jointing and pressing.

 2. Using German OMRO electrical control component to ensure efficient and stable operation.

 3. Statistic and production date recording with encoder.

 4.Incredibly easy to use with Japanese micro-computer control system

 5. Following CE standard and user-friendly features to make more stable and reliable,

 assuring a world quality.

 6.Accommodating different wood size requirement and multiple levels of wood moisture and

 hardness.

 7.Compact and efficient production process and multiple senor feedback ensures its stability in

 operation compared to others.

 8.Using noise-free technology together with cushioning and noise-proof processing for vibration

 parts to lower noise, increase machine stability and service life.

 9.Proper dust-collecting design can connect either central or individual dust-collecting device,

 minimizing sawdust emission.

 10. Customized level of automation - from manual to fully automatic.

 11. Almost all types of glue can be used with the relevant adhesive pump.





Working Procedure



Workshop





Showroom



Certificate











Remark:

• Payment: 100% in advance, 30% for deposit, balance before shipment.

• Delivery time: 5-20 days after deposit received

• Overseas Service/Training/Installation: Available

• Inspection: Detailed report with photos to be provided before shipment

• Warranty: 1 year under normal operation, except easy-damaged parts and electrical elements

• 12-hours online service: Available

• OEM service: Accepted

• Cost-benefit: Gewinn makes you cost- saved and lower your risk with high quality woodworking machines









Company Features
1. As a new production base, Gewinn United Co., LTD. is rising.
2. By using imported raw material and high technology, the quality of is guaranteed.
3. We always abide by the notion of customer-orientation. We have been attempting to offer clients services and products that make them really feel fulfilled or products that really cater to their markets.
