  • Based on good business reputation, high-quality products, and professional services, Gewinn wins unanimous praise from domestic and foreign customers.
Company Advantages
1. Gewinn is made by using the finest quality materials and leading techniques.
2. It ensures a flat spectral response. Its material will maintain a neutral appearance without color cast even as the projector lighting changes.
3. The will be well packed by our standard export cartons.
4. Gewinn United Co., LTD. adheres to the cooperation with domestic and foreign customers with the purpose of 'consistent with the contract'.

Quick Details

  • Condition:New

  • Spindle Speed:6750r.p.m

  • Air Pressure:6-8bar

  • Max. Working Width:150MM

  • Max Working Height:150MM

  • Place of Origin:Guangdong, China (Mainland)

  • Brand Name:YONGQIANG

  • Model Number:FJL150A

  • Voltage:380v

  • Dimension(L*W*H):8000x6000mm

  • Weight:8T

  • Certification:CE, IQNet

  • Warranty:1 year

  • After-sales Service Provided:Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:EPE foam and PE bag warped



This woodworking finger jointing line  is recognized as the most stable method of creating

length joints between two solid wood or wooden composite components. It is used

in order to produce very long wood components or to separate out knots and cracks

which lower the strength. Using finger joints it is possible to joint short pieces

of wood into one, in principle, infinitely long strand of wood.



Product Description





Expert in wood Finger jointing line for 27 years



Our finger jointing line, offers a particularly workable solution for length joints processing for both vertical and horizontal finger joints ,with belt conveyor, finger joint shaper (with glue), roller conveyor, chain conveyor, using extremely user-friendly , easy-operated, noise-free system to achieve high precision effect





woodworking semi-auto finger jointing machine FJL150A

Semi-auto Wood working finger jointing production line

Model NO.: FJL 150A

Parameter



Technical Parameters

woodworking semi-auto finger jointing machine FJL150A



Full Automatic Finger Joint Line  FJL 150A

Wood entry length

150-900mm

Shaping wood thickness

20-150mm

Cutting table width

450mm

Wood width

20-80mm

Wood thickness

30-150mm

Tenon spindle dia.

Φ50mm

Tenon rotary speed

6750r.p.m

Hogger spindle dia.

Φ30mm

Hogger rotary speed

2840r.p.m

Max. Wood exit length

2500mm

press force

7500kg

Shaper spindle power

11kw X 2

Hogger power

4kw X 2

Scoring power

0.75kw X 3

Hydraulic system power for Press

4kw

Saw blade power for Press

4kw

Belt conveyor power

0.75kw

Roller conveyor power

0.75kw

Total Power

41.75kw

Working air pressure

6-8 bar

Machine Dimension

8000x6000mm





Benefits





Benefit you can count on

 woodworking semi-auto finger jointing machine FJL150A





l Semi-Automatic finger jointing line, to complete the process of wood finger shaping, gluing,



conveying, jointing and pressing.







l Using German OMRO electrical control component to ensure efficient and stable operation.







l Statistic and production date recording with encoder.







l Incredibly easy to use with Japanese micro-computer control system







l Following CE standard and user-friendly features to make more stable and reliable, assuring a world quality.







l Accommodating different wood size requirement and multiple levels of wood moisture and hardness.







l Compact and efficient production process and multiple senor feedback ensures its stability in operation compared to others.







l Using noise-free technology together with cushioning and noise-proof processing for vibration parts to lower noise, increase machine stability and service life.







l Proper dust-collecting design can connect either central or individual dust-collecting device, minimizing sawdust emission .







l Customized level of automation - from manual to fully automatic.







l Almost all types of glue can be used with the relevant adhesive pump.







Cetificate













Working Procedure

Workshop





Below Series models for your reference, more wooding machines you could check our websitehttp://gewinn.en.alibaba.com      www.gewinn.com.cn









Structure



Structure

















Company Information





=====================================================================









Why Gewinn?





1. As the standing council unit of Lunjiao Government wooding machine association



2 . Cooperating with premium and reliable suppliers only



3 . Experienced team with considerate exporting and shipping service offering



4 . No additional profits pricesuppliers pay to become our members



5. As the third party inspection





Remark:

  • Payment: 100% in advance, 30% for deposit, balance before shipment.

  • Delivery time: 5-20 days after deposit received

  • Overseas Service/Training/Installation: Available

  • Inspection: Detailed report with photos to be provided before shipment

  • Warranty: 1 year under normal operation, except easy-damaged parts and electrical elements

  • 12-hours online service: Available

  • OEM service: Accepted

  • Cost-benefit: Gewinn making you cost-expense saved and lower your risk with premium wooding machines only.






Company Features
1. Gewinn United Co., LTD. owns its large factory to manufacture high quality .
2. The technology strength of Gewinn United Co., LTD. improves efficiency of production.
3. Gewinn aims to be competitive in its service and . Get an offer! Gewinn United Co., LTD. will continue to strive to introduce new products and strive to be in the leading position in the industry. Get an offer!
Packaging & Shipping
Product Description

  Automatic benchtop 3 axis paint liquid dispensing machine , FD Dispenser company more than 8 years only specialized in glue dispenser robot and all the parts of dispenser products

PC controll dispenser robot promotion, accept PC commanda will be more best solution for dispenser robot



Features
*The popular robot in FD series robots
*Dispensing Area 200 X 200 X 100 ,300 X 300 X 100 and 400x400x100, 500*500*100 mm
*Dot, Lines, Arc etc. and 3D dispensing path is available.
*100 programs, 4000 points per program
*A hand-held Teach Pendant is provided for simple and intuitive programming functions
*SRE software is available for CAD file input (optional)
*Apply adhesives, cyanoacrylates, silicone, RTV, anaerobic resin, epoxy, UV cure formulations and many more fluids.
*Every robot will be with one small dispenser controller TS9150,tips barrels etc as full unit

* OEM/ODM service.





Robots provide precise control over adhesive placement, from exact beads, to repeat timed dots or potting of components. Programming is simple via a teach pendant. Even complex patterns can be created quickly. Storage is to internal flash memory allowing for up to 255 programs to be created. High speeds are achieved reducing time spent hand applying adhesives. Accuracy of placement and volume of fluid ensures zero waste, mess and error. Our robots will dispense most materials including adhesives, pastes, epoxies, gels, silicones, sealants, RTV's, grease, anaerobics, cyanoacrylates, inks and lubricants.



What's Included:

1 x Base Robot with power cord
1 x LCD Teach Pendant with cable
1 x CE Compliance kit - start/ stop box
1 x 30/55cc Syringe Mounting bracket and slide
1 x TS9150 Digital Pneumatic controller
1 x CD-ROM with manuals and user guides
1 x Syringe Kit (30cc size)
1 x Tip Kit (145 assorted tips)



3 axis dispenser robot will be more high efficient for dispensing application, above all dot,point. 2 times fast.







ModelsFD-200FFD-300FFD-400FFD-500F
Working Range X/Y/Z(mm)200/200/50300/300/100400/400/100500*500*100
Load Y-AXIS / Z-AXIS5 kg / 3 kg10 kg / 5 kg
X&Y / Z (mm/sec)0.1-500/2500.1-600/300
Resolution0.001 mm/Axis
Repetitive Positioning Accuracy+/- 0.01 mm/ Axis
Program Capacity100 Programs,4000 points/program
Program DisplayTeach Pendant LCD
Motor SystemMicro stepping motor
Control MethodPTP & CP
Interpolation Function3 axis ( 3D )
Programming MethodTeach Pendant
I/O Signals Port8 Inputs / 8 Outputs
External Control InterfaceRS232
Power SupplyAC110 ~ 220V 300W
Working Temperature10 - 40 'C
Working Relative Humidity20 - 90% no condensation
Dimensions (WxDxH mm)385 x 370 x 500485 x 500 x 600585 x 600 x 600685 x 700 x 600
Robot Weight (kg)23 kg32 kg40 kg45 kg
