woodworking saw machine is a truly cost-effective product. It is processed in strict accordance with relevant industry standards and is up to the national quality control standards. The quality is guaranteed and the price is really favorable.Gewinn's woodworking saw machine has been substantially improved in a scientific way, as shown in the following aspects.
Company Advantages
1. Gewinn is manufactured as per the set industry production specification using the finest quality raw materials.
2. The product meets international standards in all aspects, such as performance, durability, availability and more.
3. Adopt strict quality control system to provide strong guarantee for product quality.
4. Whether the motivations are economic, environmental, or personal, the benefits of this product will have something to offer for everyone.
5. Whether the motivations are economic, environmental, or personal, the benefits of this product will have something to offer for everyone.

Quick Details

  • Condition:New

  • Place of Origin:Hebei, China (Mainland)

  • Model Number:CGPB-50PZ / CGPB-61PZ / CGPB-70PZ

  • After-sales Service Provided:Engineers available to service machinery overseas


Product Description

HF wood board assembling machine/high frequency board jointing equipment

(Vertical Lifting) (with feeding & discharging device)

( 5-80mm thickness board )



Model No.: CGPB-50PZ / CGPB-61PZ /CGPB-70PZ



This plane board jointing machine is the updated version of high frequency board jointing machine, with upper plate adopts vertical lifting and installs the synchronous system, so as to achieving higher planeness, saving 0.3mm plane thickness .







Working Procedure  : HF wood board assembling machine/high frequency board jointing equipment





 Gluing → Infeeding → Vertical Press → Horizontal Press

Heating → Vertical&Horizontal Press Closing → End product Pushing







Detailed Images

 Model Details of HF wood board assembling machine/high frequency board jointing equipment







Parameter

 Technique Data of HF wood board assembling machine/high frequency board jointing equipment



Type

CGPB-50PZ

CGPB- 61PZ

CGPB-70PZ

CGPB-120PZ

Workbench size (mm)

2500×1300

2500×1300

2500×1300

2500×1300

Jointing thickness (mm)

6-50

6-80

8-80

8-80

Vertical pressure (T)

28

28

28

42

Horizontal pressure (T)

22

33

42

78

Overall size

 (mm)

8700(L)×4400(W)

×2300(H)

8700(L)×4400(W)

×2300(H)

10200(L)x4400(W)

x2300(H)

18200(L)x5200(W)

x2400(H)

Weight (T)

         5.5

6.5

7.5

13

Feeding

Auto

Auto

Auto

Auto




Benefits

 Benefit you can count on :

1. High Timber Outturn : 5%-10% more on average compared to the general clamp carrier

2. High Efficiency : 1-3 mins to finish one board , especially processing in winter much more significant

3. Energy Saving :15-30kw/h power consumption for 1cbm board jointing

4. Low Labor Cost :feeding & discharging device of belt-conveyer , adding palletizing and gluing system for option to get more efficient as well

5. Heavy Frame :  Using large-scale machine tool to ensure its verticality

6. Easy Operation: Touch screen HML, with a built-in operation instruction which including installation, operation, repair, maintenance etc.

7. Safety :Adding high sensitive spark protection circuit and make separated cabinet for HF parts

8. Good components :assorting Taiwan pneumatic tools mostly

9. The thinnest board of jointing is 6mm at least, 80mm max thickness



Application

Application : HF wood board assembling machine/high frequency board jointing equipment



It mainly apply to laminated woodparticle board,door panel jointing, and solid wood, door pocket, door line banding, or other wooden block gluing etc.









===============================================================================





Remark:

  •  Payment: 100% in advance, 30% for deposit, balance before shipment.

  •   Delivery time: 5-20 days after deposit received

  • Overseas Service/Training/Installation: Available

  •   Inspection: Detailed report with photos to be provided before shipment

  •   Warranty: 1 year under normal operation, except easy-damaged parts and electrical elements

  •   12-hours online service: Available

  •  OEM service: Accepted

  •  Cost-benefit: Gewinn making you cost-expense saved and lower your risk with premium wooding machines only.
