hydraulic finger joint machine for sale high-performance for carpentry

Latest products

Woodworking table saw/sliding table saw SW-400B

finger cutting machine /woodworking finger joint shaper

separator dust collector / woodworking dust

No cracking, no bending high frequency wood dryer

Product Information
Feedback

Gewinn finger joint line, from residual wood to high class product

Build process

Finger jointing is recognized as the most stable method of wood length joints. And if you require this technology, Gewinn will offer you solutions in highest cost performance with quality/ price/ service mixed.

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-1

Why us?

1.Factory since 1988,over 30 years focus on finger joint technology , hundreds of manufactures are making profits with our finger joint lines.

2.High operational capacity, process speed up to 40m/min, over 19km/8h-shiftr.

3.Our finger joint can process shortest residual wood of 8cm long, maximum your production, minimum your cost.

4. CE certificate

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-2

finger joint shaper series:

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-3

MH1525F (chain conveyor)

-- Cut after press, ensure every long piece is in the same length.

About factory

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-5

A. Finger Jointing Line assembly and testing workshop

B. Finger Joint Shaper assembly and testing workshop

C. Finger Joint Composer assembly and testing workshop

Other options

MHB1560A , for 6 meters finger joint pressing

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-6

Type	MHB1560A
Size of working table	6000×580mm
Max.pressing dimensions	6000×150×80mm
Saw blade power	2.2kw
Hydraulic system power	3.75kw
Max.thrust for oil pressure	7500kg
Infeed conveyor power	1.1kw×2+0.75kw
Saw blade spindle diameter	Φ30mm
Saw blade spindle speed	2840rpm
Total motor power	8.9kw
Overall dimensions	7600×1400×1800mm

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-7

Type	MHB1560A
Size of working table	6000×580mm
Max.pressing dimensions	6000×150×80mm
Saw blade power	2.2kw
Hydraulic system power	3.75kw
Max.thrust for oil pressure	7500kg
Infeed conveyor power	1.1kw×2+0.75kw
Saw blade spindle diameter	Φ30mm
Saw blade spindle speed	2840rpm
Total motor power	8.9kw
Overall dimensions	7600×1400×1800mm

MHB1545A , for 4.5 meters finger joint pressing（optional with fully enclosed cover）

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-8

Type	MHB1545A
Size of working table	4500×580mm
Max.pressing dimensions	4500×150×80mm
Saw blade power	2.2kw
Hydraulic system power	3.75kw
Max.thrust for oil pressure	7500kg
Infeed conveyor power	1.1kw×2+0.75kw
Saw blade spindle diameter	Φ30mm
Saw blade spindle speed	2840rpm
Total motor power	8.9kw
Overall dimensions	6000×1400×1800mm

MHB1525A , for 2.5 meters finger joint pressing

--two working table , one pressing ,another feeding, more efficient.

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-9

Type	MHB1525A
Size of working table	2500×580mm
Max.pressing dimensions	2500×150×80mm
Saw blade power	2.2kw
Hydraulic system power	3.75kw
Max.thrust for oil pressure	7500kg
Infeed conveyor power	1.1kw×2+0.75kw
Saw blade spindle diameter	Φ30mm
Saw blade spindle speed	2840rpm
Total motor power	8.9kw
Overall dimensions	3960×1400×1800mm

MHB1525E ,for 2.5 meters finger joint pressing,belt conveyor.

Type	MHB1525E
Size of working table	2500×380mm
Max.pressing dimensions	2500×80×40mm
Saw blade power	2.2kw
Hydraulic system power	3.75kw
Max.thrust for oil pressure	3000kg
Infeed conveyor power	1.1kw+0.75kw
Total motor power	7.8kw
Overall dimensions	4850×1255×1370mm

Operation video

According production capacity need, we have full automatic finger joint line and semi-automatic finger joint line series.

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-11

Full Automatic Finger Jointing Line(Motor-Driven)

Finger jointing is recognized as the most stable method of wood length joints

Gewinn hydraulic finger joint machine for sale high-performance for carpentry-12

Finger joint semi-automatic line

Gewinn finger joint line, from residual wood to high class product
