high-quality woodworking machinery supplier easy-operation for bulk production

Quick Details

Condition:New
Place of Origin:Guangdong, China (Mainland)
Model Number:NE550
After-sales Service Provided:Engineers available to service machinery overseas
Touching control screen:Delta
PLC&Fenquency:Delta
pneumatic component:Korean imported pneumatc device
End-trimming:American "Parker"
trimming motor:Italy "Teknomotor" high speed motor
low voltage apparatus:Schneider
tracking wire:Germany wire
pathway:extra heavy
working voltage:380V/50HZ/3 phase
heat-up time:20 minutes

Packaging & Delivery

Packaging Details:	standard export packing/as you require

Gewinn woodworking machinery supplier easy-operation for bulk production-1

This model of edge banding machine include Pre-milling. Edge banding. End-trimming. Rough trimming. Profile trimming. Scraper. Buffing these process. make sure the wood pieces can be processed perfectly.

Gewinn woodworking machinery supplier easy-operation for bulk production-2

Equipment Details

1."Delta" PLC system control and HMI control box with "Delta" toucing screen. easy to operate.

Gewinn woodworking machinery supplier easy-operation for bulk production-3

2.Double layers feeding table. prevent the heat from the glue box effectively.

5.5L gluing box and special paint coat. shorten the melting time.

Gewinn woodworking machinery supplier easy-operation for bulk production-5

3.Korean pneumatic device. make sure the machine can work under any weather.

Gewinn woodworking machinery supplier easy-operation for bulk production-6

4.American "Parker" End-trimming unit and Germany wire. assure precisous cutting and the edge banding machine stable working for long time.

Gewinn woodworking machinery supplier easy-operation for bulk production-7

Gewinn woodworking machinery supplier easy-operation for bulk production-8

5. Rough and Profile trimming units are individually controlled by Italy “Teknomotor”

high speed motors and micrometric adjustment with Germen “SIKO” numerical digital

read-out. which ensure the edge banding machine precise trimming effect and easy adjusting.

Gewinn woodworking machinery supplier easy-operation for bulk production-9

Optional device

1.Corner Rounding device. individually controlled by Italy "Teknomotor" high speed motor

Gewinn woodworking machinery supplier easy-operation for bulk production-10

2.Optional Atomizing unit. prevent the hot melting glue remaining on the board.

Gewinn woodworking machinery supplier easy-operation for bulk production-11

Technical Parameter

Min workpiece width	60mm
Min workpiece length	100mm
workpiece thickness	10-60mm
Edge Height	15-65mm
Edge thickness	0.4-3mm
Conveyar speed	12-16-20m/min
Total power	14.7KW
Compressed Air Pressure	6.5kg/cm3
Total weight	1950kg
Over size	5400x1000x1600mm

Gewinn woodworking machinery supplier easy-operation for bulk production-12

Gewinn woodworking machinery supplier easy-operation for bulk production-13

Application

Gewinn woodworking machinery supplier easy-operation for bulk production-14

Gewinn woodworking machinery supplier easy-operation for bulk production-15

t******r

Gewinn woodworking machinery supplier is professionally designed. Its design includes material design, system design, mechanical design and component structure design. Our staff will promptly give our response to customers

k******k

The components or parts used in Gewinn woodworking machinery supplier are required to pass relevant requirements. They will be inspected or tested for strength, hardness, durability, and other mechanical properties using different testing methods.

n******p

Gewinn woodworking machinery supplier goes through a complete design cycle. It includes drawing up specifications, conception&architecture of the mechanism, design and simulation of behavior with static, dynamic, thermal, etc. Hanway follows the principle of customer first

h******m

Materials used for Gewinn woodworking machinery supplier has been tested. The tests include toughness or brittleness testing, hardness testing, tensile testing, etc. We make products according to customer's own drawing design

l******z

During the design stage, Gewinn woodworking cnc machine is exclusively designed adopting the most advanced technologies that are extensively applied in mechanical industry, such as energy-saving technology. Hanway has gained utility model patent certificate for the innovation of products

j******r

This product has an outstanding quality that exceeds industry standards. Hanway follows the principle of customer first
