high-end woodworking machinery supplier easy-installation

Quick Details

• Condition:New

• Type:Band Saw

• Use:Woodworking

• Style:Horizontal

• Place of Origin:Guangdong, China (Mainland)

• Brand Name:Gewinn

• Model Number:MJR650

• Usage:Solid wood cutting

• Voltage:380V

• Power(W):18.5KW

• Dimension(L*W*H):8300x2260x2550mm

• Weight:45000KG, 4500kg

• Certification:CE

• Warranty:1 year

• After-sales Service Provided:Engineers available to service machinery overseas

• suitable material:rosewood furniture. solid wood. over sized round wood

• Max working size:650x650mm

• Dia of saw wheel:710mm

• wood thickness:2-350mm

• wood feeding speed:0.2-13m/min

• max working length:4300mm

• saw blade tension:60-100kg/cm

• saw wheel elevate motor:0.37kw

• Saw wheel rotating motor:18.5kw

Packaging & Delivery

This band sawing is designed for rosewood furniture. solid wood and over sized round wood sawing. aim at cutting wood panel from the original wooden pillar. to make the beautiful and smooth wood panel.

  Components of  band sawing

A - Control Box

B - Electric Component

C - Saw Wheel

D - Steel Overlapped Feeding Table

E - Saw Blade

F - Rexroth SL Guide

Model Details of band sawing

1.Microcomputer operator interface. easy control.

2.High precise encoder and rigid ball screw rod to control sawing width.

3.System can save information.

4.Adopt human intelligence NC electrical system.

5.Large gantry-type structure. designed for big size wood.

6.Transmission platforms and moving saw base are adopt straidetermined using SL precise setting guide moving.

Package

Application

How to choose a band saw

1.Application: for cutting logs or cutting planks

2.Log diameter or plank height and width

3.wood hardness degree

4.If use it frenquently,we suggest to buy a band saw with a larger cutting diameter
