hydraulic joint making machine high-performance for wood

Gewinn finger joint line, from residual wood to high class product

Build process

Finger jointing is recognized as the most stable method of wood length joints. And if you require this technology, Gewinn will offer you solutions in highest cost performance with quality/ price/ service mixed.

hydraulic joint making machine high-performance for wood-1

Why us?

1.Factory since 1988,over 30 years focus on finger joint technology , hundreds of manufactures are making profits with our finger joint lines.

2.High operational capacity, process speed up to 40m/min, over 19km/8h-shiftr.

3.Our finger joint can process shortest residual wood of 8cm long, maximum your production, minimum your cost.

4. CE certificate

hydraulic joint making machine high-performance for wood-2

Finger joint shaper series:

hydraulic joint making machine high-performance for wood-3

MXB 3515E(S) motor drive or soft and medium hard wood finger joint shaping.

--With glue spreader, auto gluing reduce labor manual work.

hydraulic joint making machine high-performance for wood-4

hydraulic joint making machine high-performance for wood-5

---With top and Bottom scoring saw, to prevent any damage on the edge when finger shaping.

Type	MXB3515E(S)
Size of working table	500×650mm
Shaping thickness	20-150mm
Min.working length	100mm
Max.working width	450mm
Hogger spindle diameter	Φ30mm
Shaper spindle diameter	Φ50mm
Hogger spindle speed	2840rpm
Shaper spindle speed	5600rpm
Shaper spindle power	11kw
Hogger power	4kw
Power for conveyor	0.75kw
Top & Bottom scoring saw power	0.75kw×2
Total motor power	17.25kw
Overall dimensions	2350×1650×1450mm

About factory

hydraulic joint making machine high-performance for wood-6

A. Finger Jointing Line assembly and testing workshop

B. Finger Joint Shaper assembly and testing workshop

C. Finger Joint Composer assembly and testing workshop

Other options

MXB3515D motor drive , for soft and medium hard wood finger joint shaping.

hydraulic joint making machine high-performance for wood-7

Type	MXB3515D
Size of working table	500×650mm
Shaping thickness	20-150mm
Min.working length	100mm
Max.working width	450mm
Hogger spindle diameter	Φ30mm
Shaper spindle diameter	Φ50mm
Hogger spindle speed	2840rpm
Shaper spindle speed	5800rpm
Shaper spindle power	11kw
Hogger power	4kw
Power for conveyor	0.75kw
Total motor power	15.75kw
Overall dimensions	1900×1650×1450mm

MXB3515E motor drive , for soft and medium hard wood finger joint shaping.

--With glue spreader, auto gluing reduce labor manual work.

hydraulic joint making machine high-performance for wood-8

hydraulic joint making machine high-performance for wood-9

Type	MXB3515E
Size of working table	500×650mm
Shaping thickness	20-150mm
Min.working length	100mm
Max.working width	450mm
Hogger spindle diameter	Φ30mm
Shaper spindle diameter	Φ50mm
Hogger spindle speed	2840rpm
Shaper spindle speed	5800rpm
Shaper spindle power	11kw
Hogger power	4kw
Power for conveyor	0.75kw
Total motor power	15.75kw
Overall dimensions	2250×1650×1450mm

Operation video

According production capacity need, we have full automatic finger joint line and single machine series.

hydraulic joint making machine high-performance for wood-10

Full Automatic Finger Jointing Line(Motor-Driven)

Finger jointing is recognized as the most stable method of wood length joints

hydraulic joint making machine high-performance for wood-11

Finger joint press

Gewinn finger joint line, from residual wood to high class product

z******x

Gewinn United Co., LTD.'s finger joint shaper uses high-quality raw materials, durable products, long service life, scientific product structure design, excellent overall performance, and excellent workmanship, from details to the whole.

y******p

As a professional joint making machine manufacturer, Gewinn United Co., LTD. has rich production experience, advanced production equipment, superb production technology and strong production strength, capable of producing high-quality joint making machine.

n******u

The finger joint shaper manufactured by us with advanced design concepts not only strives for excellence in workmanship, scientific and reasonable design, but also has stable performance and durability, which can meet customers' needs for high-quality products.

x******a

joint making machine Produce in strict accordance with the standards stipulated by the company and the requirements of the market to ensure that it can pass the inspection of relevant state departments and meet the national quality standards. It is a high-quality product with guaranteed quality.

g******e

Gewinn United Co., LTD. The pursuit of excellence, adhere to the use of advanced concepts, high-quality materials and exquisite craftsmanship joint making machine, effectively guarantee the rationality of the structure joint making machine and the stability of performance, the quality is trustworthy.

g******i

The product features the desired safety. During electrical testing, all live components, conductors, terminals and measuring instruments are well protected to prevent accidental contact. It will provide durable and cost-efficient operation for decades
