quality woodworking equipment marketing for tenoning

Quick Details

Condition:New
Type:Table Panel Saw
Use:Woodworking
Style:Horizontal
Place of Origin:Guangdong, China (Mainland)
Usage:wood panel sawing
Voltage:380V
Dimension(L*W*H):5790*6200*1525mm
Weight:4200kg
Certification:CE
Warranty:1 year
After-sales Service Provided:Engineers available to service machinery overseas
Control Screen:Taiwan ASK LCD
PLC:Japan Mitsubishi
Main saw motor:Italy motor
Scoring saw motor:Taiwan quality motor
Electronic protect:Taiwan AC contactor
Machine frame:one-stop finish
feeding part1:Japan servo motor
feeding part2:Switzerland gear reducer
feeding part3:high precision limit switch
warranty:1 year

Packaging & Delivery

Packaging Details:	standard packing
Delivery Detail:	within 30 days

quality woodworking equipment marketing for tenoning-1

Gewinn United is engaged in the exporting business in the filed of woodworking

machinery. well known the local information in the country of woodworking machine

in China. We promise only supply the good quality products with our best service.

Advantage

1.Japan servo motor equip with Switerland gear reducer

2.With dust cover to protect working environment

3.with emergency switch to protect worker

4.German gear track

5.Emergency switch

6.conveying by rack and pionion.precision cutting

Specification of automatic reciprocating saw

HI-SPEED COMPUTER PANDEL SAW	HH-PRO-10-HC
Max cutting depth	100mm
Max cutting length	3250mm
Main saw blade	Φ405mm
Main saw spindle	Φ30mm
Speed of main saw	4800r/min
Scoring saw blade	Φ180mm
Spindle of Scoring saw blade	Φ30
Speed of Scoring saw blade	6500r/min
cutting speed	0-50m/min
return speed	80m/min
Main saw motor	20HP (25HP for option)
Saw carriage motor	3HP
Blower motor	5HP
Auto-feeding system	2kw AC servo motor
Auto-feeding speed	0-60m/min
Working air-pressure	7kg/cm2
Table height	920mm
Dimension (LWH)	579062001525mm
Net weight	4200kg
Gross weight	4800kg

Detail Parts Introduction

1.Taiwan ASK LCD control screen

quality woodworking equipment marketing for tenoning-2

2.Japan Mitsubishi PLC

quality woodworking equipment marketing for tenoning-3

3.Feeding parts

quality woodworking equipment marketing for tenoning-4

German gear track.stable working without slip.

quality woodworking equipment marketing for tenoning-5

4.Sawing device

quality woodworking equipment marketing for tenoning-6

Scoring saw blade

quality woodworking equipment marketing for tenoning-7

5.Emergency switch

quality woodworking equipment marketing for tenoning-8

6.Durable copper wheel for saw carriage moving

quality woodworking equipment marketing for tenoning-9

7.Air-floating table with steel ball

quality woodworking equipment marketing for tenoning-10

quality woodworking equipment marketing for tenoning-11

Products

quality woodworking equipment marketing for tenoning-12

quality woodworking equipment marketing for tenoning-13

quality woodworking equipment marketing for tenoning-14

l******t

Gewinn woodworking equipment is professionally designed. Its design includes material design, system design, mechanical design and component structure design. Hanway has been specialized in aluminum, zinc and brass die casting for over 13 years

g******j

The components or parts used in Gewinn woodworking equipment are required to pass relevant requirements. They will be inspected or tested for strength, hardness, durability, and other mechanical properties using different testing methods. We make products according to customer's own drawing design

u******a

Gewinn woodworking machines for sale goes through a complete design cycle. It includes drawing up specifications, conception&architecture of the mechanism, design and simulation of behavior with static, dynamic, thermal, etc. Maintaining a mutually beneficial relationship with customers is a part of our core values

u******n

Materials used for Gewinn woodworking machines for sale has been tested. The tests include toughness or brittleness testing, hardness testing, tensile testing, etc. Maintaining a mutually beneficial relationship with customers is a part of our core values

q******h

During the design stage, Gewinn woodworking equipment is exclusively designed adopting the most advanced technologies that are extensively applied in mechanical industry, such as energy-saving technology.

f******k

This product has an outstanding quality that exceeds industry standards. Creating an atmosphere of trust and recognition to encourage employees is also one of our missions
