full function wood edge banding machine automatic machine furniture

Product Information of full function wood edge banding machine automatic machine furniture

Product Details

Gewinn pursues excellent quality and strives for perfection in every detail during the production.woodworking saw machine, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.

Company Advantages
1. The selection of materials for Gewinn wood edgebander machine is meticulous. It takes into consideration physical properties (density, melting point, elec/thermal properties, etc.) and mechanical properties (stiffness, elasticity, plasticity, etc.).
2. It has gone through strict quality test before it is packed.
3. The product meets the international quality standards and can withstand any rigorous quality and performance tests
4. The product has no burrs and its edges are extremely smooth. Customers say they would prefer to repurchase it for their hardware stores.
5. I bought this product and has used it for a certain time. I already found that its light is clear without any shadow.

Quick Detail

Condition:New
Place of Origin:Guangdong, China (Mainland)
Model Number:NE400
After-sales Service Provided:Engineers available to service machinery overseas
Touching control screen:Delta
PLC&Fenquency:Delta
pneumatic component:Korean imported pneumatc device
End-trimming:American "Parker"
trimming motor:Germany high speed motor
low voltage apparatus:Schneider
tracking wire:Germany wire
pathway:extra heavy
working voltage:380V/50HZ/3 phase
heat-up time:20 minutes

Packaing & Deliery

Packaging Details:	standard export packing/as you require

Product Description

full function wood edge banding machine automatic machine furniture-1

Automatic edge banding machine

This Automatic edge banding machine is can band PVC, Veneer tape.Suitable for home use cabinet, closet, drawer and office furniture manufacturing. Precise trimming unit is helpful to make smooth product.

MAIN TITLEModel Details of Wood Edge Banding

full function wood edge banding machine automatic machine furniture-2
Parameter of wood edge banding

Parameter of Wood Edge Banding

Specification		NE550R	NE500R	NE400R	NE550	NE450	NE500	NE400	NE300	NE200
Min. Effectiven Workpiece Width		60mm
Min. Workpiece Length		150mm			100mm
Min. Workpiece Size (All Size)		100×150mm			100×100mm
Workpiece Thickness		10-60mm
Edge Height		15-65mm
Edge Thickness		0.4~3mm
Conveyor Speed		12~16~20 m/Min
Total Power		17KW	11.5KW	10KW	14.7KW	12.5KW	10.5KW	8KW	8KW	7.3KW
Compressed Air Pressure		6.5kg/cm³
Voltage		380V/50Hz/3phase
Total Weight		2450KG	2150KG	1900KG	1950KG	1800KG	1650KG	1500KG	1350KG	1150KG
Overall Size	L	6610mm	5660mm	5210mm	5400mm	5000mm	4500mm	4000mm	3550mm	2910mm
	W X H	1000×1600mm								1000×1420mm

Benefits YOU Can Count On

-Equipped with ‘DELTA’ PLC system and HMI controlled with touch screen, assure a simple and steady operation.

-Equipped with Korean pneumatic device, ensures all-weather adaptability under different temperature conditions.

-Banding of edges up to 3 mm in thickness

-Double layers edge feeding table, which protects the sealing edge by reducing the heat from the glue melting box.

-Available with a board pre-heating device, which ensures a better glue joint effect especially in low working temperature environment.

-Equipped with American ‘Parker’ End-trimming unit, assure precise end trimming and perfect results.

-Rough and Profile trimming units are individually controlled by Italy ‘Teknomotor’high speed motors and micrometric adjustment with Germen “SIKO” numerical digital read-out.

-Optional high speed pre milling device for a better edging effect. (two motors are individually controlled by frequency converter, with two diamond saws, sawing height:60mm)

-Corner Rounding device, which is individually controlled by Italy ‘Teknomotor ‘high speed motors and micrometric adjustment with Germen “SIKO” numerical digital read-out.

-Optional Atomizing unit, which can prevent the hot melting glue remaining on the board.

Advantages of Wood Edge Banding

full function wood edge banding machine automatic machine furniture-3

Factory

full function wood edge banding machine automatic machine furniture-6

Packaing &Shipping

full function wood edge banding machine automatic machine furniture-7

Application

full function wood edge banding machine automatic machine furniture-8

Structure of Wood Edge Banding

full function wood edge banding machine automatic machine furniture-9

A- Gluing System

B - Presser Device

C - End Trimming Device

D - Rough Trimming Device

E - Profile Trimming Device

F - Scraper Device

G - Corner Rounding Device

H - Buffing Device

Video

Sample display

full function wood edge banding machine automatic machine furniture-10

full function wood edge banding machine automatic machine furniture-11

full function wood edge banding machine automatic machine furniture-12

full function wood edge banding machine automatic machine furniture-13

Company Features
1. Gewinn United Co., LTD. primarily provides wood edge banding machine for global customers.
2. The solid technology competency greatly improves quality of edge banding machine manufacturers .
3. We bring a fresh perspective and infectious energy to every client relationship. Our emphasis on teamwork, trust, and tolerance for diverging opinions helps clients focus on their opportunities, build their capabilities and win the future. We work hard to meet customer demand for environmentally optimal products. We combine our industry knowledge with the renewable, recyclable and biodegradable materials to manufacture innovative products. Our commitment to our customers has been at the core of who we are. We're committed to constantly creating and reinventing with the singular purpose of making a real difference for our customers. Our company aims to be a long term, reliable supplier with a wide product range and solid product quality. We will put more effort into improving our manufacturing abilities.
