Your reliable woodworking machinery supplier.
This CNC tenoning machine can make kinds of tenons on solid wood or laminated MDF, with 45°, 90°, 135°, finish both tenon and mortis. Machine can save 50 processing programs, helpful to improve production efficiency.
1.Technology features:4-in-1 functions including mortise,tenon,trimming and options of the cutting angle at 45 degree,90 degree and 135 degree.
2.Applications:cabinets,wardrobe,photo frames ect..the frame structure is very beautiful,high-precision,convenient and simple for using.The Unique techique with pre-milling process can solve various difficult problem about wood edge abrasion.
3.Convenience:The location and size of mortise and tenon are easy to set in computer,which can pre-store 50 product programs.
What we can make
Type | CNC1200C |
Table size | 1200×470 |
Tenon cutter shaft diameter (mm) | 30 |
A drill chuck type | ER 25 |
A cutter diameter(mm) | 6-16 |
Machining of workpiece width(mm) | 30-130 |
Machining of workpiece thickness(mm) | 10-70 |
Mortising depth(mm) | 0-45 |
Total power | 9.2kw |
Tenon cutter speed | 12000 r/min |
Mortising bit | 18000 r/min |
Pressure | 0.5-0.8mpa |
voltage | 380V |
Weight(t) | 2.2 |
Dimension (mm) | 2550(L)×1260(W)×1900(H) |
Operation video
1.If the process is more complex,need to adjust the equipment in the process,we can customize your tenon structure.
